DC cable in Peshawar

Single-core copper cable for solar arrays, inverter-to-battery runs, and DC power circuits. Made on our own line in Lahore and delivered anywhere in Peshawar in 2–4 days — at the day's factory rate, with no dealer margin on top.

WhatsApp for today's rate See the price list

Coils of red and black double-core solar DC cable with a close-up of the stranded copper conductors

Sizes we make

All DC cable sizes

Class 5 stranded copper, XLPE/PVC insulated for a 90°C conductor rating. Single core. Sizes below link to full specifications.

56 / 0.30 MM

4mm²

Small rooftop arrays and panel strings.

84 / 0.30 MM

6mm²

Mid-size solar strings and charge controllers.

80 / 0.40 MM

10mm²

Inverter-to-battery bank runs.

126 / 0.40 MM

16mm²

Larger battery banks and combiner runs.

196 / 0.40 MM

25mm²

Multi-kW inverter feeders.

276 / 0.40 MM

35mm²

Large system main DC feeders.

What each size carries

Class 5 stranded copper conductor per IEC 60228. Current capacity and voltage drop per BS 7671, installation reference method C (clipped direct), 30°C ambient, two loaded conductors, PVC-reference figures. This cable's XLPE/PVC insulation is rated to 90°C conductor temperature — real-world capacity on an open rooftop run typically exceeds the PVC figures shown; confirm with your installer. Derate for conduit, bundling, and high ambient temperature.
Size	Current capacity	Voltage drop
4 mm²	36 A	11 mV/A/m
6 mm²	46 A	7.3 mV/A/m
10 mm²	63 A	4.4 mV/A/m
16 mm²	85 A	2.8 mV/A/m
25 mm²	112 A	1.75 mV/A/m
35 mm²	138 A	1.25 mV/A/m

Match the size to your array or inverter current, and check the run length for voltage drop — a long rooftop-to-inverter run needs a bigger cable, not a smaller one. Confirm sizing with your installer, or start with the cable size calculator.

Get today's rate for Peshawar

Cable prices move with the daily copper rate, so we quote on the day. Send the size, the length, and how many runs you need — we reply with the factory price and dispatch from Lahore.

WhatsApp for today's rate
